Smittybilt 12k Steel

$582.99

  • INCLUDED WITH THE XRC GEN3 WINCH:
    • FORGED WINCH HOOK
    • STEEL CABLE W/ ROLLER FAIRLEAD
    • MOVEABLE CONTROL BOX BRACKET.4”

In stock

Warranty: Lifetime

Description

GENERAL SPECIFICATIONS XRC GEN3 12K STEEL SERIES
Cable/Rope Type Steel
Part Number 97612
Regular List Price
$549.99
Fairlead Type Roller
Rated Line Pull 12000lb
Motor 7.0 HP
NEW! Load Indicator System YES
NEW! Controller Flashlight
YES
NEW! Aluminum Tie Bar Light
YES
NEW! Detachable Body Armor
YES
NEW! 12 Volt Power Outlet
YES
NEW! Control Box DRL
YES
NEW! High-Visibility Clutch Lever
YES
NEW! Dual-Magnet Controller Mount
YES
Moveable Control Box
YES
Int’l Waterproof Rating IP67
Electrical Warranty 5 years
Mechanical Warranty LIFETIME
LINE SPEED/AMP DRAW
Line Pull – lb 0 3000 6000 9000 12000
Line Pull – Kg 0 1364 2727 4082 5433
Line Speed – Ft/min 25 14.7 12.8 8 5.2
Line Speed – M/min 7.6 4.5 3.9 2.4 1.6
Motor – AMPS 90 160 230 300 375
LINE PULL/CABLE CAPACITY
Layers of Cable 1 2 3 4
Rated Line Pull, per Layer – lb 12000 10270 9200 8800
Rated Line Pull, per Layer – kg 5440 4654 4169 3790
Cumulative Cable – ft 16 42 72 80
Capacity – m 5 12 21 24

Additional information

Weight 85 lbs
Dimensions 30 × 15 × 15 in
